Two AMS1117 regulator boards at an angle, black with gold edges: the 3.3 V board in front with its chip, four small capacitors and three holes labelled GND, OUT and VIN, and the adjustable board behind it with the same layout and no LED.

You have thisams1117

AMS1117 LDO Regulator Kit, 24 Boards (18 × 3.3 V, 6 × Adjustable)

Eighteen fixed 3.3 V boards and six adjustable ones that turn a higher supply into a steady lower voltage. What to feed them, which pin is which, how much current before heat stops them, and how to set the adjustable board.

Boards: 18 + 63.3 V + ADJ
Input for 3.3 V: 4.4–12V
Heat it can shed: 0.8W
