The TK50 at an angle: two cream-coloured transducer cans with square-mesh fronts standing on a black board with a gold border, lonely binary and open-source is love printed behind them, a sound-wave symbol between them, ULTRASONIC DISTANCE SENSOR along the bottom edge above four header pads, and a right-angle four-pin header's pins reaching out past that edge.
VR

View it in VR

This board opens in a VR headset: life-size, or big enough to stand beside, with every pin and every part named where it sits. Open this address in the browser on a headset such as Apple Vision Pro or Meta Quest.

learn.lonelybinary.com/vr/tk50
You have this

Ultrasonic Distance Sensor

Distance by echo timing, on an RCWL-9616 that runs from 3 to 5 V and speaks GPIO, I2C, UART or 1-Wire, chosen by two solder jumpers. No divider on a 3.3 V board. Soft and angled surfaces are where it quietly lies to you.

Supply
3–5V, no divider needed
Range
2cm to about 3 m
Accuracy
±1cm under a metre
Interfaces
GPIO, I2C, UART, 1-Wiretwo solder jumpers pick one
Start here · 01 What the echo measuresOpen the board in 3D

Turn it over and pick a mode: all four holes in GPIO, I2C and UART, three in 1-Wire, where TRIG carries everything and ECHO is left empty. Nothing sits between the chip and the header, so VCC is your board's logic voltage.

Product questions & answers ↓
