The kit laid out: twelve small black 74HC595 driver boards shown front and back with their pin names in white silkscreen, twenty-four seven-segment digits showing red numerals and letters, most of them snapped into grey printed frames, four strips of male pin header, and a stack of spare frames with dark filter windows.

You have this056seg

24-Pack 0.56" 7-Segment LED with 74HC595 Driver

A 24-pack of 0.56" seven-segment digits and twelve 74HC595 driver boards: three wires instead of eight, which digit is common cathode and which is common anode, how the ten pins line up, and the current limit that bites on 8.

Digits: 2412 of each kind
Character: 0.56inch, red
Wires needed: Threehowever many digits
Whole chip: 70mA maximum
