4″ 7-Segment LED Display with 74HC595

The newer 4-inch digit, with a PWM pad for dimming (the earlier version had none). Its own shift register, six signal wires from your board, a 12 V supply for the segments, and modules that plug into each other to make longer numbers.

Digit
4inch
Segments
12V, its own supply
Logic
3.3 / 5V
Brightness
PWMone pin, or short the pad
Start here · 01 Seven segments and a dotOpen the module in 3D

Turn it over, click any of the eight holes on the IN edge, then lift the display off to see the shift register, the driver and the PWM switch it covers.

Product questions & answers ↓

The whole handbook16 articles · 80 minQuick reference (PDF)PDF · 537 KBDatasheetPDF · ti.comDatasheetPDF · ti.comDatasheetPDF · aosmd.com3D model (GLB)GLB · 4.8 MBCAD model (STEP)ZIP · 11.7 MBDrawing (PDF)PDF · 2.6 MBDrawing (DXF)ZIP · 123 KBPinout and specsThe pin table, and the questions people ask first
