Hall Effect Sensor
An omnipolar Hall switch on a TinkerBlock board: bring either pole of a magnet near and SIGNAL goes LOW and a red light comes on. No contact to wear out, it works through plastic, and it looks at the field every 22 ms, so it is made for doors, lids and slow wheels.
beginnerModuleUpdated
Linear Hall Effect Sensor
An SS49E-type linear Hall sensor on a TinkerBlock board: an analog voltage that rests at half of VCC with no field and moves about 3.25 mV per gauss at 5 V, up for one pole and down for the other. It tells you how strong a magnetic field is and which way it points. VCC must be your board's logic voltage, and it is not a current sensor on its own.
