seven segment
2 pages across tutorials, modules, pinouts and guides.
beginnerModule
0.56-inch 7-Segment Digits with a 74HC595 Driver Board
A 24-pack of 0.56" seven-segment digits and twelve 74HC595 driver boards: three wires instead of eight, which digit is common cathode and which is common anode, how the ten pins line up, and the current limit that bites on 8.
beginnerModuleUpdated
74HC595 Segment LED
One 0.8-inch red seven-segment digit with a 74HC595 shift register under it, on a TinkerBlock board: three wires set all eight segments, one byte per digit, a 1 lights a segment. Common cathode, 150 Ω per segment, VCC on your board's logic supply, and no chaining: the 595's serial output is not connected.
