Fundamentals/RS-485 and Modbus

Two wires, one difference, many stations.

RS-485 is how a serial line reaches far and serves many; Modbus is the conversation on top. Shown as a workshop bench with numbered stations, a foreperson who sends job tickets and a gauge that reads which of two rails is higher. Twelve short lessons, each with a bench you can press, on a laptop, a phone or in a VR headset.

Why a plain serial line fails on a long run, how two wires carry a difference, what common mode is, how many stations share one trunk, one driver at a time, and the two ends.

Who asks and who answers, what a request contains, where the data lives, the number trap in the manuals, how silence closes a frame, and what a reply, an exception and a timeout mean.
