Where does the picture live, and who keeps it alive?
A screen is not one thing, and the name of its connector does not tell you how it works. Sixteen short lessons take I2C, SPI, QSPI, 8080, RGB, MIPI DSI, LVDS and eDP in turn, each with a bench you can press on a laptop, a phone or in a VR headset, and end with how to choose a screen from the chip you have.
How much data a picture is, and why a screen is a panel, a controller, a backlight and a host that have to agree.
The four ways a host writes into a display controller's memory: I2C, SPI, QSPI and the 8080 parallel bus.
Where a frame lives, the frame buffer and what moves it, RGB timing and colour depth, and why a picture tears.
MIPI DSI lanes and modes, LVDS, eDP, and how to pick a screen starting from the chip you have.
