A card can be lost. A strip is counted.
TCP and UDP are two ways to send over the same network, shown as a classroom where a novel is torn into numbered strips for TCP and one-line cards go by UDP. Twelve short lessons, each with a bench you can press, on a laptop, a phone or in a VR headset.
What IP leaves to the application, how an address and a port find the right program, what UDP does with a datagram, and what can happen to it on the way.
The handshake, the byte stream, acknowledgements and resends, the receiver's window, congestion, and how a connection ends.
How to choose by what an app needs, what QUIC adds on top of UDP, and where all of this shows up on an ESP32.
