A mesh that sleeps.
A battery sensor in a wardrobe reaches a controller without Wi-Fi, and a wall switch turns on a light with the hub off. This course follows one real house and builds the whole idea from the instruments up: the radio, the roles, the names, joining, paths, the parent that holds a sleeping device's messages, the clusters, security, the hub, and the ESP32 on the bench. Thirteen short lessons, each with a bench you can press, on a laptop, a phone or in a VR headset.
What Zigbee is next to Wi-Fi, the shared radio, and the three roles.
Names and temporary addresses, joining and credentials, and how paths form and change.
A sleepy child and its parent, what a device can do, and reports and direct actions.
Security depends on setup, Zigbee against Thread and Matter, what happens when it fails, and the ESP32 bench.
