A light switches on, and a byte goes each way at once.
SPI is a conveyor-belt sushi restaurant for chips: the kitchen sends a plate a step, the table sends one back, and the light over the seat says which table is listening. Fourteen short lessons, each with a bench you can press, on a laptop, a phone or in a VR headset.
Why SPI exists beside I2C, what each of its four wires does, and how a byte goes out while a byte comes back.
The four clock modes, a full transaction from the light going on to the light going off, how fast it can go, and several devices on one bus.
Two, four and eight lines for flash and memory, the flash modes on an ESP32-S3, and what a wrong setting looks like.
