No clock wire. Only an agreement.
UART is how two devices send bytes with nothing but a wire each way and a ground, shown as two cottages whose switches and lamps are wired crosswise. Twelve short lessons, each with a bench you can press, on a laptop, a phone or in a VR headset.
Which wire goes where, how an idle line wakes the receiver with a start bit, how a byte becomes highs and lows, how a frame ends, and what baud means.
How a receiver reads with no clock wire, what a mismatch looks like, the buffer that can overflow, the faults a receiver can notice, and asking the other side to wait.
Why UART is not a voltage standard, and where all of this shows up on an ESP32.
