Small messages, a long way.
A soil probe has a few bytes to say a few times an hour, from far away, on a battery. This course follows that one real job on an Australian farm and builds the whole idea from the instruments up: the chirp, the settings, the airtime, the noise, the rules and the battery, then LoRaWAN, then the ESP32 on the bench. Twelve short lessons, each with a bench you can press, on a laptop, a phone or in a VR headset.
What LoRa is for, a symbol as a chirp, and what the spreading factor trades.
Bandwidth, coding and the packet, airtime as the real cost, and decoding below the noise but not through an interferer.
The rules where you live, shared spectrum and collisions, and a day in the life of a battery node.
LoRa is not LoRaWAN, LoRaWAN's message rhythm and keys, and the ESP32 on the bench.
